Reconfigurable with up to 4 separate 7A power domains
Reduces component count by up to 74%
90% Conversion Efficiency
Simplifies system design
Industry leading current density 2.8A/mm²
Controller, Switches, Inductor and Capacitor in one chip
>10MHz Regulation Bandwidth
90% Conversion Efficiency
Delivers 160 A in an 8 x 4.4mm package
4.5 A/mm² current density, highest in the industry
93% conversion efficiency
Scales to > 10 kW by ganging up to 64 devices
Allows land-side integration with dual side attach, placing it close to the load
Delivers 145 A TDC in an 8.9 x 5.6mm package | 1.2mm thick
A Dual-Sided IVR, allowing True Vertical Power Delivery
Built differently. Integrated by design.
Ferric IVRs combine the powertrain, integrated magnetics, capacitors and digital control into compact multi-phase power converters designed for high-performance computing.
More power, less space
Everything integrated
Closer to the load
Flexible integration
Product
Type
Phases
VIN (V)
VOUT (V)
ITDC (A)
Area (mm²)
ITDC / Area (A/mm²)
Thickness (mm)
Ferric Fe1767 Newport Integrated Voltage Regulator
Buck
16
1.2–2.0 V
0.25–1.5 V
145 A
49.8 mm²
2.9 A/mm²
1.2 mm
Ferric Fe1766 Integrated Voltage Regulator
Buck
16
1.2–2.0 V
0.25–1.5 V
160 A
35.5 mm²
4.5 A/mm²
1.0 mm
Ferric Fe1736 Integrated Voltage Regulator
Buck
18
1.6–2.0 V
0.25–1.5 V
56 A
20 mm²
2.8 A/mm²
0.725 mm
Ferric Fe1728 Integrated Voltage Regulator
Buck
8
(up to 4 outputs)
1.6–2.0 V
0.25–1.5 V
7, 7, 7, 7 A
15.1 mm²
1.9 A/mm²
0.725 mm
Lower Energy per Token. Lower Cost per Inference
Energy per Token (Joules/token)
(Normalized)
Lowest Energy
per token
0.76 to 0.80
0.88
Competing IVRs
1.00
Lateral Power Delivery
Lowest energy per token: 20-24% lower vs lateral power and 8-12% lower vs competing IVRs.
More compute per watt: Lower Vcore enabled by reduced droop - higher throughput and lower system power.
Why Ferric makes the best IVRs?
Ferric stands out because of its unique technical approach to solving the IVR puzzle:
Proprietary Thin-Film Magnetics: One of the hardest obstacles to putting a voltage regulator directly on or inside a processor package is the inductor. Inductors are typically bulky discrete components. Ferric bypassed this by developing CMOS-integrated ferromagnetic thin-film inductors that are built directly onto the silicon. This allows them to shrink the power supply down to a minuscule 35.5 mm² chiplet.
High Current Density for AI: Ferric's flagship product, the Ferric Fe1766, delivers an incredible 160 A at a density of 4.5A/mm². Multiple chiplets can be "ganged" together, meaning they can scale up to deliver over 10 kW of power to massive, power-hungry AI accelerators and GPUs.
Back-End-of-Line (BEOL) Integration: While some competitors build standalone power modules that sit next to the chip, Ferric focuses on Back-End-of-Line (BEOL) fabrication, integrating their thin-film magnetics directly into the chip manufacturing pipeline with foundries like TSMC.
Heavy Commercial Partnerships: Ferric is far from a theoretical startup; they are deeply integrated into the next-generation AI ecosystem. For instance, Marvell Technology partners with Ferric to embed these pre-validated integrated power solutions directly into custom AI and cloud infrastructure platforms.
